BAODING HEWEI POWER TECHNOLOGY CO., LTD.
Booth Number: Hall N4 - 4S07
Add EP Wechat for consultation
110KV DRY-TYPE CAPACITIVE CURRENT TRANSFORMER
LGB dry composite capacitive current transformer is a completely independent and innovative current transformer in China. The internal is composite film capacitor insulation, and external insulation is high-temperature vulcanized silicone rubber composite sheds. The CT is U-shaped structure, Inside the U-shaped structure is the primary current-carrying conductor. The thin film capacitor core is wound on the contactor, and the bottom is the transformer shell with built-in secondary winding. There is a measuring terminal on the bottom of the shell, which is opened for partial discharge and dielectric loss factor measurement and should be reliably grounded during normal operation. Standard: IEC61869, GB20840.
126KV DRY COMPOSITE CONDENSER BUSHING
FCRG Dry-type composite capacitive wall bushing is an independently developed and innovative product in China. The main insulation inside the bushing is divided into composite film capacitive insulation and resin-impregnated fiber capacitive insulation. The main insulation outside is divided into high-temperature vulcanized composite rubber and porcelain. which can meet the needs of different users. Standard:IEC60137,GB/T4109.
RIF CONDENSER BUSHING
RIF (resin-impregnated fiber) dry capacitive transformer bushing is often used as the outgoing bushing of transformers, which plays the role of lead fixing support and ground insulation. Structures RIF capacitive transformer bushing uses silicon rubber composite material or porcelain for external insulation, RIF composite material for internal insulation. The capacitor core uses patented stress-splitting buffer layer technology. It reduces internal stress and makes product quality stable, improves the tolerance of cold and hot shock ability, and the level of safe operation. Standard: IEC 60137.
